ASME B16.9 / B16.11 · MSS SP-97 · Available

Pipe Fittings — Buttweld, Forged & Olets

Elbows, tees, reducers, caps, couplings, unions and branch outlets in carbon (A234), stainless (A403) and alloy (A182) grades. Buttweld to ASME B16.9, forged socket-weld & threaded to B16.11, olets to MSS SP-97 — all types and sizes, available across the GCC with 3.1 / 3.2 certificates.

Request a Quote → Standards reference ● WhatsApp
Buttweld and forged steel pipe fittings
/ Overview — types of pipe fittings

Every fitting to complete your line

Pipe fittings connect, change direction, branch, reduce and terminate a piping system. AAM Steel carries the full range in three families: buttweld (BW) fittings welded to matching pipe schedules; forged socket-weld & threaded fittings for small-bore and utility lines; and branch outlet (olet) fittings for take-offs from a run pipe. All in carbon, stainless and alloy grades, matched to your pipe standard and wall thickness.

/ Families

Fitting families & standards

Buttweld (BW)

ASME B16.9 / B16.28 · A234 WPB, A403 SS, A182 alloy.

Elbow 45/90/180 LR·SRTee (equal/reducing)Reducer conc/eccCapStub EndCrossBend 3D/5D

Forged — SW & Threaded

ASME B16.11 · A105, A182 · Class 2000–9000.

Elbow 45/90Tee / CrossCoupling full/halfUnionBushingPlugCapNipple

Branch Outlets (Olets)

MSS SP-97 · matched to run/branch schedule.

WeldoletSockoletThreadoletElboletLatroletNipolet

Also available: grooved & mechanical, sanitary/hygienic (Tri-Clamp, DIN 11851), malleable iron (EN 10242), instrumentation/compression and waterworks (ductile iron) fittings.

/ FAQ

Pipe fittings — common questions

What are the main types of pipe fittings?
Elbows (45°, 90°, 180°), tees (equal & reducing), reducers (concentric & eccentric), caps, crosses, stub ends and bends for buttweld; couplings, unions, plugs, bushings and nipples for forged SW & threaded; and branch outlets (weldolet, sockolet, threadolet) for olets.
What standards cover pipe fittings?
Buttweld follows ASME B16.9 (dimensions) & B16.28 (short radius); forged SW & threaded follow ASME B16.11; olets follow MSS SP-97. Materials: ASTM A234 (carbon), A403 (stainless), A182 (alloy).
What is the difference between socket weld and threaded fittings?
Socket-weld fittings are welded to the pipe for a permanent, leak-tight joint (Class 3000/6000/9000). Threaded fittings screw onto threaded pipe for a joint that can be dismantled (Class 2000/3000/6000) — common for small-bore and utility lines.
Where can I buy pipe fittings in the GCC?
AAM Steel supplies pipe fittings available across Qatar, the UAE and Saudi Arabia in carbon, stainless and alloy grades, all types and sizes, with material test certificates. Send your list for an itemised quote.
/ Related products
Flanges Carbon Steel Pipes Stainless Steel Pipes Valves Standards Reference
Fittings RFQ

Get a pipe fittings quote

List your types, sizes, schedule/class, grade and quantities — we'll quote with MTC and delivery terms across the GCC.
