Three construction essentials: cast iron soil & waste pipe (EN 877) for building drainage, steel pipe piles & sheet piles for marine and foundation works, and scaffolding tube (EN 39 / BS 1139) for access and shoring.
AAM Steel rounds out the construction range with three specialist lines. SML cast iron soil & waste pipe to EN 877 — push-fit coupling-jointed — for building drainage, soil, waste and rainwater.
Steel pipe piles & sheet piles (spiral/LSAW to API 5L / EN 10219, and hot-rolled/cold-formed sheet piles to EN 10248 / ASTM A572) for jetty, foundation and shoring works. And scaffolding tube to EN 39 / BS 1139 (Ø48.3 mm, black or galvanized) plus formwork and shoring props for site access.
Push-fit soil, waste & rainwater drainage.
Spiral/LSAW large-diameter foundation & marine piles.
U / Z / straight-web profiles for shoring.
Ø48.3 mm access tube, black or galvanized.
| DN (mm) | OD (mm) | Jointing | Use |
|---|---|---|---|
| 50 | 58 | Push-fit coupling (grip/clamp) | Soil, waste & rainwater drainage |
| 70 | 78 | Push-fit coupling (grip/clamp) | Soil, waste & rainwater drainage |
| 100 | 110 | Push-fit coupling (grip/clamp) | Soil, waste & rainwater drainage |
| 125 | 135 | Push-fit coupling (grip/clamp) | Soil, waste & rainwater drainage |
| 150 | 160 | Push-fit coupling (grip/clamp) | Soil, waste & rainwater drainage |
| 200 | 210 | Push-fit coupling (grip/clamp) | Soil, waste & rainwater drainage |
| 250 | 262 | Push-fit coupling (grip/clamp) | Soil, waste & rainwater drainage |
| 300 | 313 | Push-fit coupling (grip/clamp) | Soil, waste & rainwater drainage |
Cast iron SML reference. Pipe-pile and scaffold-tube sizes on request.
Tell us which line — cast iron drainage, pipe/sheet piles or scaffold tube — with sizes and quantity, and we'll quote.
